Physical Properties
Chemical properties:
Ethyl cyanoacrylate
Colour:
Colourless
Viscosity @ 25°c:
1200-2500 mpa.s (cp)
Specific gravity:
1.1
Maximum gap fill:
0.4 mm (0.017 in)
Fixture/handling time (steel):
15-20 seconds
Fixture/handling time (buna n rubber):
15-20 seconds
Fixture/handling time (phenolic):
15-20 seconds
Full strength:
24 hours
Shear strength (steel):
21-25 n/mm² (3000-3600 psi)
Shear strength (aluminium):
8-9 n/mm² (1200-1300 psi)
Shear strength (zinc):
10 n/mm² (1450 psi)
Shear strength (abs):
>8 n/mm² (1200 psi)
Shear strength (pvc):
>11 n/mm² (1600 psi)
Shear strength (pc):
>5 n/mm² (700 psi)
Shear strength (phenolic):
14 n/mm² (2000 psi)
Impact strength:
3-5 kj/m² (1.4-2.4 ft-lb/in²)
Dielectric constant @ 10khz:
2.5
Dielectric strength:
25 kv/mm
Coefficient of thermal expansion:
90 x 10^-6 mm/mm/°c
Coefficient of thermal conductivity:
0.1 w/(m.k)
Hardness (iso868):
85 shore d
Storage temperature:
2°c to 7°c (35°f to 45°f)
Service temperature:
-55°c (depending on materials bonded)
