Buy in Bulk and Save!
Price Per Unit: $15.90
Price Per Box: $14.31
| Buy Boxes in Bulk and Save! | |
|---|---|
| Boxes | Price Per Box (20) |
| 1-3 | $286.20 ($14.31 each) |
| 4-6 | $257.58 ($12.87 each) |
| 7-9 | $228.96 ($11.44 each) |
| 10-19 | $214.65 ($10.73 each) |
| 20+ | $200.34 ($10.02 each) |
| Discounts are applied at the checkout cart | |
Autoshield NP60: A Technical Overview
Autoshield NP60 is a professional-grade, one-component polyurethane adhesive and sealant specifically engineered for the direct glazing of automotive glass. Its fast-curing, high-modulus formulation provides exceptional bond strength and structural integrity, making it suitable for windscreen and side glass bonding, particularly on modern vehicles with aluminium bodies. The adhesive develops strength rapidly, forming a flexible and durable seal that resists temperature extremes and weathering. Its key advantage is a primer-less adhesion capability to ceramic frit bands, streamlining the application process without compromising on safety or long-term performance.
1 HOUR
Safe Drive-Away Time. Independently crash tested to US Federal Motor Vehicle Safety Standard (FMVSS) 212, Autoshield NP60 allows for windscreen replacement that gets vehicles back on the road, and back to work, faster.
Core Features & Specifications
- FMVSS 212 Certified: Passes the federal crash test standard with dual airbags just 1 hour after application at 23°C and 50% relative humidity.
- High Modulus Formula: Delivers exceptional structural rigidity and bond strength, with a final shear resistance of over 3.5 MPa (500 psi).
- Primer-less to Ceramic: Bonds directly to clean ceramic bands, reducing preparation time and potential application errors.
- Rapid Cure Profile: Achieves a skin formation time of 20-35 minutes, allowing for efficient work progress and minimising contamination risk.
- Superior Flexibility: Offers over 700% elongation at break, easily accommodating the thermal expansion, contraction, and body flex of a vehicle without stress fractures.
- Excellent Temperature Resistance: Maintains performance integrity in service temperatures ranging from -40°C to +90°C, suitable for all Australian climate zones.
The Autoshield NP60 Advantage
- Maximise Workshop Throughput: The 1-hour safe drive-away time allows auto glaziers to complete more jobs per day, increasing revenue and customer satisfaction.
- Reduce Call-Backs & Liability: Using a crash-tested adhesive that meets OEM safety standards provides peace of mind and reduces the risk of bond failure and associated liabilities.
- Simplify Your Workflow: The ability to apply NP60 directly to prepared ceramic bands saves critical time on each job and simplifies inventory by reducing primer usage.
- Achieve OEM-Level Structural Integrity: The high-modulus formula restores the vehicle's body rigidity to original specifications, which is critical for modern vehicle safety systems and handling.
- Deliver Durable, All-Weather Performance: Excellent resistance to water, salt spray, and temperature extremes ensures a reliable, long-lasting bond that won't degrade over the vehicle's lifespan.
Best Practices: Do's & Don'ts
Do
- Ensure all bonding surfaces are clean, dry, and free from contaminants before application.
- For plain glass without a ceramic band, use Autoshield Activator AP1001 followed by Autoshield GB Primer.
- Abrade ceramic bands with a fine Scotch-Brite pad using 5 back-and-forth movements to remove residues.
- Apply the adhesive bead in a consistent, well-defined triangle shape for optimal contact.
- Store cartridges at approximately 20°C before use in cold weather to ensure smooth application viscosity.
Don't
- Do not touch the prepared bonding area after cleaning and activation.
- Never clean the old polyurethane bead with an alcohol-based solution as it can inhibit the cure.
- Do not apply in the presence of cured or uncured silicone or hybrid (MS/SPUR/STPE) sealants.
- Do not apply the adhesive at ambient temperatures below 5°C.
- Do not use Autoshield Activator if it appears cloudy; this indicates moisture contamination.
Applications in Practice: Trade Scenarios
For Mobile Auto Glaziers: Rapid Roadside Replacement
The On-Site Challenge
Completing a windscreen replacement on-site requires speed and reliability. You need to guarantee a safe bond quickly, so the customer can use their vehicle without a long waiting period, regardless of the weather.
The System-Based Solution with Autoshield NP60
Autoshield NP60's 1-hour drive-away time is your key advantage. After preparing the ceramic band (abrade and clean) and applying the V-bead of NP60, the vehicle is safe to drive in 60 minutes. This allows you to complete the job, finalise paperwork, and move to the next customer efficiently.
Best Practice Note
In temperatures between 5°C and 15°C, double all drying times for primers and activators to ensure a full cure. Keeping the NP60 cartridge inside your vehicle before use will ensure optimal flow rate from the gun.
For Auto Body Shops: OEM-Standard Structural Repairs
The Engineering Challenge
When performing structural repairs, the windscreen is a critical component of the vehicle's chassis rigidity and airbag performance. Your adhesive must restore this integrity to OEM standards to ensure safety and avoid costly call-backs or liability issues.
The System-Based Solution with Autoshield NP60
Autoshield NP60 is a high-modulus adhesive, meaning it contributes significantly to the vehicle's torsional stiffness. Its FMVSS 212 crash-test certification provides documented proof of its ability to hold the windscreen in place during a collision, ensuring correct airbag deployment and maintaining roof crush resistance.
Best Practice Note
For maximum structural integrity, ensure the pinchweld is clean, dry, and correctly primed. A consistent, unbroken triangular bead of adhesive is crucial for ensuring 100% contact and eliminating stress points.
Performance Benchmark: Autoshield NP60 vs. Standard Alternatives
| Metric | Autoshield NP60 | Standard PU Adhesive | Advantage |
|---|---|---|---|
| Safe Drive-Away Time (Dual Airbags) | 1 Hour Excellent | 4-8 Hours | Dramatically faster vehicle return-to-service, improving workshop efficiency. |
| Safety Certification | FMVSS 212 Crash Tested Certified | Often none or self-certified | Independently verified performance provides the highest level of safety assurance. |
| Primer-less Adhesion | Yes (to Ceramic Bands) Good | No (Primer always required) | Fewer steps in the application process, saving time and reducing risk of error. |
| Shear Strength (7 days) | >3.5 MPa High Strength | ~2.5 MPa | Provides superior structural integrity and long-term durability for the life of the vehicle. |
Frequently Asked Questions
What is the certified Safe Drive-Away Time (SDAT) for Autoshield NP60?
Autoshield NP60 has a certified Safe Drive-Away Time of just 1 hour for vehicles equipped with dual airbags. This is based on independent crash testing conducted according to the rigorous FMVSS 212 standard at 23°C and 50% relative humidity.
Do I need to use a primer with Autoshield NP60?
Autoshield NP60 is a primer-less adhesive when applied to clean, intact ceramic frit bands on the windscreen. For bonding to plain glass without a ceramic band, or for bare metal scratches on the vehicle body, you must use the Autoshield Activator and GB Primer system to ensure proper adhesion.
How should I prepare the surface before applying Autoshield NP60?
Clean the bonding area of the ceramic band with a quality glass cleaner to remove impurities. For the old adhesive bead left on the vehicle frame, clean it in a single pass with a lint-free cloth dampened with acetone. Do not use any alcohol-based cleaners on the old bead.
What is the cure time for Autoshield NP60?
While the vehicle is safe to drive after 1 hour, a full cure takes longer. Autoshield NP60 cures at a rate of approximately 3mm per 24 hours at 23°C and 50% relative humidity. The skin formation time is around 20-35 minutes.
Can I use Autoshield NP60 on vehicles with aluminium bodies?
Yes, Autoshield NP60 is particularly suitable for bonding windscreens on vehicles with aluminium bodies. Its non-corrosive formulation and high-strength bond are ideal for modern vehicle construction, ensuring a safe and durable installation.
Applications & Benefits
| Application / Use Case | Key Benefit | Primary Trades |
|---|---|---|
| Direct Glazing Windscreen Replacement | 1-hour safe drive-away time (FMVSS 212 tested) maximises job throughput and vehicle safety. | Automotive Glaziers, Collision Repair Specialists |
| Side and Rear Stationary Glass Bonding | High green strength and fast cure provide a strong, reliable bond for all fixed vehicle glass. | Automotive Glaziers, Body Repair Shops |
| Bonding Glass to Aluminium Frames | Specifically formulated for excellent adhesion and performance on modern aluminium bodies. | Collision Repair Specialists, Custom Vehicle Builders |
| Primer-less Application to Ceramic Bands | Saves significant time (15-60 mins) and reduces the potential for adhesion failure from incorrect priming. | Automotive Glaziers |
Applying Autoshield NP60: Enhanced Protocols & Best Practices
-
Glass & Body Preparation
Correct preparation is non-negotiable for a safe installation. Ensure all surfaces are free from contamination.
Windscreen Ceramic Band
Clean the ceramic band with a glass cleaner. For optimal results, lightly abrade the band with a very fine Scotch Brite pad to remove manufacturing residues.
Vehicle Pinchweld
Trim the old PU bead to 1-2mm height. Clean the trimmed bead and pinchweld with Acetone. If there are bare metal scratches, touch up with paint and prime with Autoshield GB Primer.
Pro Tip: Never use alcohol-based solutions to clean the old adhesive bead, as this can compromise the cure of the new Autoshield NP60 adhesive. -
Primer Application (If Required)
Primer is only required on plain glass or bare metal repairs. Do not apply primer to the ceramic frit band.
For Plain Glass
First, use Autoshield Activator with the wipe-on, wipe-off method. Then, apply a thin, even film of Autoshield GB Primer with a clean dauber.
Drying Time: Allow primer to dry for a minimum of 15 minutes and a maximum of 60 minutes before applying the adhesive. -
Adhesive Application & Glass Setting
Cut the cartridge nozzle to create a triangular bead. Apply a continuous, even bead of Autoshield NP60 to the glass or pinchweld.
Working Time: The windscreen must be set in place and pressed firmly before the adhesive skins over (approx. 20-35 minutes at 23°C).Clean-Up: Clean any uncured sealant immediately with Cleaner T or acetone. Once cured, the adhesive can only be removed mechanically.
Limitations & Safety
Product Limitations
Do not apply in the presence of cured or uncured silicone or hybrid sealants (MS, SPUR, STPE), as this can inhibit the cure.
Minimum application temperature is 5°C. In colder conditions (5-15°C), primer drying times must be doubled.
Do not use Autoshield Activator if the liquid appears cloudy, as this indicates moisture contamination.
Never use alcohol-based cleaners on the old adhesive bead or bonding surfaces, as it will prevent a proper cure.
Safety & Handling Requirements
Personal Protective Equipment
Wear protective gloves (nitrile rubber recommended), safety glasses/goggles, and suitable work clothing. Avoid skin and eye contact.
Ventilation & Respiratory
May cause allergy or asthma symptoms if inhaled. Use only in well-ventilated areas. In case of inadequate ventilation, wear a suitable organic vapour/particulate respirator (AS/NZS 1715/1716).
Emergency First Aid
Eyes:
Causes serious eye irritation. Rinse opened eye for several minutes under running water. If symptoms persist, consult a doctor.
Skin:
Causes skin irritation. Immediately wash with plenty of water and soap. If irritation continues, consult a doctor.
Inhaled:
If breathing is difficult, remove victim to fresh air and keep at rest. If respiratory symptoms occur, call a POISON CENTRE or doctor.
Swallowed:
Do not induce vomiting. Seek medical advice immediately.
If medical advice is needed, have product container or label at hand.
Autoshield NP60 Adhesion & Preparation Guide
Ceramic Frit Band (Windscreen)
Surface Preparation
Ensure the ceramic band is free from impurities by cleaning with a suitable glass cleaner. For best results, slightly abrade the ceramic band with a Scotch Brite Very Fine (Red) pad (5 back-and-forth movements) to remove any silicone residues from the glass manufacturing process.
Primer Requirements
Primer-less application
Autoshield NP60 is designed for primer-less adhesion to clean and properly prepared OEM ceramic frit bands.
Plain Glass (No Ceramic Band)
Surface Preparation
The glass must be perfectly clean and dry. Apply Autoshield Activator using the "wipe on/wipe off" method: apply with one clean, lint-free cloth and wipe off immediately (within 30-60 seconds) with a second clean, lint-free cloth.
Primer Requirements
Primer system required
After activation, apply a thin, uniform film of Autoshield GB Primer with a clean applicator. Allow primer to dry for a minimum of 15 minutes and a maximum of 60 minutes before applying NP60.
Autoshield Activator & GB PrimerVehicle Body (Pinchweld)
Surface Preparation
Cut the existing polyurethane bead, leaving a clean, level profile of 1-2mm. Clean the remaining bead and surrounding paintwork with acetone on a lint-free cloth to remove contamination. Do not use alcohol-based cleaners.
Primer Requirements
Primer required for bare metal
If the pinchweld paint is intact, no primer is needed. For any bare metal scratches, touch up with paint and then apply Autoshield GB Primer to the area to prevent corrosion and ensure adhesion. Allow primer to dry for 15-60 minutes.
Autoshield GB Primer
